Flamma® 648 Sulfo-NHS ester

• Covering the full spectral range from UV to NIR
• Equipped with a variety of reactive groups: NHS and Sulfo-NHS ester, Vinylsulfone, Maleimide, Click chemistry, isothiocyanate, hydrazide and hydrophobic substances.
• High quantum yields and photostability
• High purity and compatible with most of biomolecules

• Superior Water Solubility: Ideal for aqueous-based experiments and live-cell imaging
• Brightness: High extinction coefficient for enhanced sensitivity
• Stability: Generates stable fluorescence signals for reliable results
• Versatility: Compatible with various biomolecules and applications
• Ease of Use: No need for organic co-solvents, simplifying experimental procedures

Flamma^® Fluors NHS ester / Sulfo-NHS ester

Succinimidyl (NHS) esters are reliable activating moiety for amine labeling due to the formation of the strong amide bond. NHS esters are generally stable when storing in anhydrous and the dark condition at -20. NHS ester dyes display good reactivity toward aliphatic amines yet low reactivity with aromatic amines, alcohols, phenols and histidine. The basicity of an amine is an important factor for its reactivity: virtually all proteins have lysine residues, and most of them have a free N-terminus amine. The reactivity of ε-amino group at lysine is pH dependent that the optimal pH for labeling lysine residue is 8.5~9.5. However, the primary amine at N-terminus usually has a pKa value of ~7, thus it can be selectively conjugated by running the reaction in neutral pH. Due to the solubility issue, Flamma^® Fluors NHS esters are required to be dissolved in an organic solvent such as DMSO or DMF and added to aqueous solution. To overcome this limitation, BioActs offers water soluble Flamma^® Fluors Sulfo-NHS ester dyes, which can eliminate the usage of organic solvents in the conjugation reaction. NHS and Sulfo-NHS ester dyes are unstable under humid condition, thus they should be in a lyophilized form or a solution in the anhydrous organic solvent such as DMF or DMSO and stored at -20 ℃.


Figure 1.   Absorption (upper) and emission (bottom) spectra overlap of Flamma^® Fluors

Figure 2.   Immunofluorescence imaging and in situ hybridization imaging

Figure 3.   Fluorescence images of Flamma^® 749 (upper) and Flamma^® 774 (bottom) carboxylic acid injected mouse

Citation & Reference

1. Lim, Chang-Keun. Phthalocyanine-aggregated polymeric nanoparticles as tumor-homing near-infrared absorbers for photothermal therapy of cancer. Theranostics 2.9 (2012): 871-879.
2. Park, Jin Woo. Novel cyanine dyes with vinylsulfone group for labeling biomolecules. Bioconjugate chemistry 23.3 (2012): 350-362.
3. Lim, Chang-Keun. Gadolinium-coordinated elastic nanogels for in vivo tumor targeting and imaging. Biomaterials 34.28 (2013): 6846-6852.
4. Keunsoo Jeong. Poly (oxyethylene sugaramide) s: unprecedented multihydroxyl building blocks for tumor-homing nanoassembly. Journal of Materials Chemistry B 1.28 (2013): 3437-3442.
5. Lee, So Jin. TNF-α gene silencing using polymerized siRNA/thiolated glycol chitosan nanoparticles for rheumatoid arthritis. Molecular Therapy 22.2 (2014): 397-408.
6. Yoon, Hong Yeol. Photo-crosslinked hyaluronic acid nanoparticles with improved stability for in vivo tumor-targeted drug delivery. Biomaterials 34.21 (2013): 5273-5280.
7. Park, Solji. Amphiphilized poly (ethyleneimine) nanoparticles: a versatile multi-cargo carrier with enhanced tumor-homing efficiency and biocompatibility. Journal of Materials Chemistry B 3.2 (2015): 198-206.
8. Lee, Eunjung. Co-delivery of chemosensitizing siRNA and an anticancer agent via multiple monocomplexation-induced hydrophobic association. Journal of Controlled Release 210 (2015): 105-114.
9. Xu, Peisheng. Zwitterionic chitosan derivatives for pH-sensitive stealth coating. Biomacromolecules 11.9 (2010): 2352-2358.
10. Ibrahim, Basma M. A strategy to deliver genes to cystic fibrosis lungs: a battle with environment. Journal of controlled release 155.2 (2011): 289-295.
11. Oh, Keun Sang. Accurate sequential detection of primary tumor and metastatic lymphatics using a temperature-induced phase transition nanoparticulate system. International journal of nanomedicine 9 (2014): 2955.
12. Yhee, Ji Young. Tumor-targeting transferrin nanoparticles for systemic polymerized siRNA delivery in tumor-bearing mice. Bioconjugate chemistry 24.11 (2013): 1850-1860.
13. Yoon, Hong Yeol. Glycol chitosan nanoparticles as specialized cancer therapeutic vehicles: Sequential delivery of doxorubicin and Bcl-2 siRNA. Scientific reports 4 (2014).
14. Ryu, Ju Hee. Early diagnosis of arthritis in mice with collagen?induced arthritis, using a fluorogenic matrix metalloproteinase 3–specific polymeric probe. Arthritis & Rheumatism 63.12 (2011): 3824-3832.
15. Hollis, Christin P. In vivo investigation of hybrid paclitaxel nanocrystals with dual fluorescent probes for cancer theranostics. Pharmaceutical research 31.6 (2014): 1450-1459.
16. Koo, Heebeom. The movement of self-assembled amphiphilic polymeric nanoparticles in the vitreous and retina after intravitreal injection. Biomaterials 33.12 (2012): 3485-3493.
17. Zhu, Lei. Real-time monitoring of caspase cascade activation in living cells. Journal of controlled release 163.1 (2012): 55-62.
18. Yoon, Hong Yeol. Bioreducible hyaluronic acid conjugates as siRNA carrier for tumor targeting. Journal of Controlled Release 172.3 (2013): 653-661.
19. Yhee, Ji Young. Cancer-targeted MDR-1 siRNA delivery using self-cross-linked glycol chitosan nanoparticles to overcome drug resistance. Journal of Controlled Release 198 (2015): 1-9.
20. Park, Jin Woo. Wide-Ranged Fluorescent Molecular Weight Size Markers for Electrophoresis. Bulletin of the Korean Chemical Society 34.1 (2013): 29-30.
21. Huang, Xinglu. Multiplex Imaging of an Intracellular Proteolytic Cascade by using a Broad Spectrum Nanoquencher. Angewandte Chemie International Edition 51.7 (2012): 1625-1630.
