Automated ELISA processors (BIOBASE2000)
Automated ELISA processors (BIOBASE2000)
Cat. No. DCBio-BIOBASE2000
Description
It is complete solution for your IVD ELISA assays. The system combines a high precision pipetting unit with stable incubations and efficiency washers and photometer unit.
Features
- 1 robotic arm, 2 pipetting probe(10~1000μl).
- 4 unit 96 well microplates(independent incubating).
- 1 unit reader& washer (auto reading and washing).
Software Module
- User-friendly Windows system;
- LIS system available.
Sample Module
Hitech teflon coating probe to prevent cross contamination.
Sample & Reagent & Dilution Rack Module
Original sample tubes available; Rack positions programmable.
Microplate Reader & Washer Module
Modularized automatic control reading and washing system.
For more details please see the below video:
Model
|
Model |
DCBio-BIOBASE2000 |
||
|
Sample Unit |
Sample Racks |
Standard 192 sample positions(expandable, up to 552) |
|
|
Pipetting |
10~1000μl |
||
|
Dispensing System |
2 aspirating-dispensing probe with X-Y-Z movement; |
||
|
Reagent Unit |
Reagent Position |
23 reagent racks, editable |
|
|
Pipetting Range |
10~1000μl, 1μl stepping |
||
|
Pipetting precision |
(100ul) CV≤0.5% |
||
|
DispensingTime |
4 minutes to whole 96 to microplates |
||
|
Washing Unit |
WashingProbes |
Two line 8-nozzle manifolds |
|
|
Wash Containers |
Cleaning fluid(15L), waste water(25L), Buffer 1(5L), Buffer 2(2L), Buffer 3(2L), Buffer 4(2L), with liquid level-sensing, liquid shortage and full alarm |
||
| Waste Containers | 25L with waste full sensor | ||
|
Washing Residual |
<2μl |
||
|
Reading Unit |
ReadingChannels |
8 independent photometric channels, mono and dichromatic reading |
|
|
Absorbance |
0.0 ~3.0 OD |
||
|
Spectral Range |
400-700nm |
||
|
Optical Filters |
2 standard filters(450, 630nm); 2 more on request (405nm/450nm/492nm/630nm) |
||
| Reading Accuracy | ±1% from 0~1.5OD, ±2% from 1.5~3.0OD | ||
| Incubation Unit |
Incubators |
4 independent units | |
|
Temperature Range |
RT to 45℃ | ||
|
Temperature Accuracy |
±0.5℃ | ||
|
Data Management |
Software |
Above Windows 7 system |
|
|
LIS System |
Bi-direction, support HL7 protocol |
||
|
Results |
Absorbance and results reviewable by software |
||
|
Printer |
External optional |
||
|
Working Conditions |
Power Supply |
AC220V±10%,50/60Hz, 110V±10%,60Hz, 400W |
|
|
Temperature |
10～30℃ |
||
|
Humidity |
30-80% |
||
|
Size & Weight |
External Size (W*D*H) |
1235*705*875mm |
|
|
Net Weight |
146kg |
||
|
Package Size (W*D*H) |
1380*860*1435mm |
||
|
Gross Weight |
220kg |
||
Note: This product weighs over 50 pounds and requires a liftgate truck for delivery. However, if you have a loading dock for delivery trucks, a liftgate truck may not be necessary. For more information, click here >>> go or refer to the FedEx website >>> go.
