- Home
- FluxMPS™ RPMI 1640 Medium, High Glucose w/o L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate: 1X Liquid
FluxMPS™ RPMI 1640 Medium, High Glucose w/o L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate: 1X Liquid
FluxMPS™ RPMI 1640 Medium, High Glucose w/o L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate: 1X Liquid
FluxMPS™ RPMI 1640 Medium, High Glucose w/o L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate: 1X Liquid is a Microfluidics Suitable, quadruple-stage ultra-filtered cell culture medium engineered for organ-on-a-chip (OoC), tissue-on-a-chip (ToC), and microphysiological system (MPS) applications. Processed through a validated filtration train (0.1 µm ×2 + 0.04 µm ×2), it reaches a 0.04 µm final cut-off — well beyond conventional 0.22 µm-filtered media — making it microchannel-safe from day one.
- Quadruple-stage filtration: 0.1 µm (Prefiltration I & II) + 0.04 µm (Final filtration I & II), reaching a 0.04 µm final cut-off
- Endotoxin release specification: < 0.05 EU/mL (USP <85> BET), controlled per manufacturing batch
- High-glucose RPMI 1640 base (4500 mg/L D-glucose); formulated without L-glutamine, sodium pyruvate, and sodium bicarbonate for full user-defined supplementation
- Prepared with Ultrapure Type 1 water (18.2 MΩ·cm) and filled in an ISO Class 5 aseptic environment
- Manufactured under an ISO 13485:2016 quality management system with per-batch QC and Certificate of Analysis
- Mycoplasma risk mitigated via 0.1 µm mycoplasma-retentive filtration (not tested per lot)
- Custom formulations available — pH, glucose, salts, HEPES, and nutrient composition on request
- Glucose4500 mg/L (4.5 g/L)
- L-GlutamineNot added — supplement as needed
- Sodium PyruvateNot added
- Sodium BicarbonateNot added — supplement to set CO₂ requirement
- pH (USP <791>)7.4
- Osmolality (USP <785>)See CoA
- Endotoxin (USP <85>)< 0.05 EU/mL
- Filtration0.1 µm ×2 + 0.04 µm ×2 (Quadruple-stage)
- Storage2–8°C, protect from light
- Shelf Life12 months from date of manufacture, unopened
Engineered where standard media fails
Conventional 0.22 µm-filtered media carry mycoplasma-sized particulates (0.2–0.3 µm) and subvisible debris that can accumulate inside microchannels, corrupting biosensor readings and shortening device lifetimes. FluxMPS™ is engineered to address these failure modes at the source.
Microchannel-safe purity
Sequential 0.1 µm mycoplasma-retentive stages plus a 0.04 µm final polish deliver an ultra-low particulate load; USP <788> Method 1 (light obscuration) particulate compliance verified per lot.
Total metabolic control
Supplied without L-glutamine, sodium pyruvate, or sodium bicarbonate, giving full control over carbon source and buffering for metabolic flux experiments.
Ultrapure-grade water
Prepared with Type 1 water (18.2 MΩ·cm) meeting ASTM D1193 / ISO 3696 purity standards, supporting trace-metal and organic-carbon (TOC) control.
Low background for imaging
Low particulate baseline reduces optical noise from debris and aggregates — well suited for confocal microscopy, live-cell biosensors, and TEER measurements.
Rich, stable nutrient profile
Micro-batch precision manufacturing locks in amino acid and vitamin concentrations, ensuring lot-to-lot reproducibility critical for long-term perfusion studies.
Customization on demand
pH, glucose, salts, HEPES, and full nutrient composition available on request. Contact support@diagnocine.com.
Quadruple-stage filtration system
FluxMPS™ RPMI 1640 Medium, High Glucose w/o L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate: 1X Liquid is processed through a four-stage serial filtration sequence reaching 0.04 µm — engineered to reduce mycoplasma-sized particulates, subvisible particles, and bioburden beyond what 0.22 µm filtration achieves.
-
1
0.1 µm Prefiltration I
Removes large particulates, cell debris and protein aggregates; protects the first 0.04 µm final filter cartridge.
-
2
0.04 µm Final filtration I
First 0.04 µm pass; retains sub-micron particulates and microaggregates that pass through 0.22 µm filtration.
-
3
0.1 µm Prefiltration II
Second dedicated prefilter, protecting the second 0.04 µm final filter cartridge.
-
4
0.04 µm Final filtration II — Polish
Ultimate polishing filter; aseptic fill & finish in a validated ISO Class 5 laminar-flow workstation.
Performance vs. conventional media
Four sequential stages reaching a 0.04 µm final cut-off — two dedicated prefilter + final-filter pairs in series — with USP <788> Method 1 particulate compliance verified on every lot.
© Diagnocine® — DCP-RPMIG-QPB1X
Designed for next-generation cell culture platforms
FluxMPS™ RPMI 1640 Medium, High Glucose w/o L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate: 1X Liquid is validated for organ-on-a-chip, metabolic research, live-cell imaging, and primary cell models where particulate contamination and endotoxin variation are unacceptable.
Automated Bioreactors & Robotics
An optional 0.01 µm (10 nm) ultra nano-filtered MPS Grade variant is available for automated bioreactor and robotic perfusion systems requiring the ultimate particulate exclusion.
- Total Particulate Exclusion: 10 nm filtration for nanoscale valve and sensor protection
- Valve & Sensor Protection: prevents particulate-induced blockage in precision fluidic systems
- Extended Perfusion Stability: maintains flow rate consistency across multi-week automated runs
Inquiry Required: Contact support@diagnocine.com to request the 0.01 µm MPS Grade variant.
Micro Physiological System (MPS) & Chip
Ultra-filtered formulation prevents microchannel clogging and maintains laminar flow integrity.
Warburg Effect & Metabolic Research
Defined high-glucose base and low-endotoxin background enables precise metabolic flux analysis.
iPSC-Derived Models
Ultrapure formulation supports sensitive iPSC differentiation protocols.
Endothelial & Primary Cells
Microchannel-safe purity essential for maintaining endothelial barrier integrity and TEER values.
Metabolic Flux Analysis
Defined high-glucose base supports isotope tracing (13C) and NMR-based metabolic flux analysis. Not compatible with Agilent Seahorse XF assays, which require bicarbonate-free, phenol red-free medium.
Microscopy & Optical Sensing
Ultra-low particulate load supports high-content confocal imaging and biosensor integration.
Lot-release quality parameters
Every production lot of FluxMPS™ RPMI 1640 Medium, High Glucose w/o L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate: 1X Liquid undergoes the complete quality-release battery below before shipment.
| Parameter | Specification |
|---|---|
| Formulation | RPMI 1640, High Glucose; contains Phenol Red, Calcium, Magnesium; without L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate, HEPES |
| Appearance | Red-colored, clear solution |
| pH USP <791> | 7.4 |
| Osmolality USP <785> | See CoA |
| Glucose | 4500 mg/L (4.5 g/L) |
| L-Glutamine | Not added — supplement as needed |
| Sodium Pyruvate | Not added |
| Phenol Red | Present (5.300 mg/L) |
| Parameter | Specification |
|---|---|
| Endotoxin USP <85> BET | < 0.05 EU/mL |
| Sterility USP <71> | No growth after 14 days |
| Mycoplasma | 0.1 µm mycoplasma-retentive filtration (not tested per lot) |
| Particulate ≥10 µm USP <788> Method 1 | Compliant |
| Particulate ≥25 µm USP <788> Method 1 | Compliant |
| Water purity | Ultrapure Type 1, 18.2 MΩ·cm |
| Manufacturing std. ISO 13485 | ISO 13485:2016 |
| Fill environment | ISO Class 5 (Class 100) |
| Parameter | Specification |
|---|---|
| Storage temperature | 2–8°C, protected from light |
| Freeze-thaw | Not recommended |
| Shelf life | 12 months from date of manufacture, unopened |
| Shipping condition | Cold pack |
| CO₂ requirement | Sodium bicarbonate not added — add NaHCO₃ or HEPES to set your target CO₂ tension (2.0 g/L NaHCO₃ typically supports 5% CO₂) |
| Parameter | Specification |
|---|---|
| Raw material grade | Cell culture / reagent grade |
| Traceability | Full lot documentation, CoA available |
| Manufacturing QMS | ISO 13485:2016 certified |
| UNSPSC | 41116155 — Molecular biology and cell culture growth media (UNv260801) |
| Regulatory alignment | 21 CFR Part 820 (QMSR) aligned |
| Production method | Micro-batch precision manufacturing |
| Intended use | For Research Use Only (RUO) |
Full composition (mg/L)
Complete formulation with CAS numbers, reproduced from manufacturer specification. Total: 38 components across 4 categories (Inorganic Salts, Amino Acids, Vitamins, Others). Custom compositions available on request.
| Component | CAS Number | mg/L |
|---|---|---|
| INORGANIC SALTS | ||
| Calcium nitrate tetrahydrate | 13477-34-4 | 100.000 |
| Magnesium sulfate anhydrous | 7487-88-9 | 48.840 |
| Potassium chloride | 7447-40-7 | 400.000 |
| Sodium chloride | 7647-14-5 | 6000.000 |
| Sodium phosphate dibasic anhydrous | 7558-79-4 | 800.000 |
| Component | CAS Number | mg/L |
|---|---|---|
| AMINO ACIDS | ||
| Glycine | 56-40-6 | 10.000 |
| L-Arginine hydrochloride | 1119-34-2 | 241.000 |
| L-Asparagine | 70-47-3 | 50.000 |
| L-Aspartic acid | 56-84-8 | 20.000 |
| L-Cystine dihydrochloride | 30189-89-0 | 65.200 |
| L-Glutamic acid | 56-86-0 | 20.000 |
| L-Histidine hydrochloride monohydrate | 5934-29-2 | 20.960 |
| L-Hydroxyproline | 51-35-4 | 20.000 |
| L-Isoleucine | 73-32-5 | 50.000 |
| L-Leucine | 61-90-5 | 50.000 |
| L-Lysine hydrochloride | 657-27-2 | 40.000 |
| L-Methionine | 63-68-3 | 15.000 |
| L-Phenylalanine | 63-91-2 | 15.000 |
| L-Proline | 147-85-3 | 20.000 |
| L-Serine | 56-45-1 | 30.000 |
| L-Threonine | 72-19-5 | 20.000 |
| L-Tryptophan | 73-22-3 | 5.000 |
| L-Tyrosine Disodium Salt | 69847-45-6 | 28.830 |
| L-Valine | 72-18-4 | 20.000 |
| Component | CAS Number | mg/L |
|---|---|---|
| VITAMINS | ||
| Choline chloride | 67-48-1 | 3.000 |
| D-Biotin | 58-85-5 | 0.200 |
| D-Ca-Pantothenate | 137-08-6 | 0.250 |
| Folic acid | 59-30-3 | 1.000 |
| Niacinamide | 98-92-0 | 1.00 |
| Pyridoxine hydrochloride | 58-56-0 | 1.00 |
| Riboflavin | 83-88-5 | 0.200 |
| Thiamine hydrochloride | 67-03-8 | 1.000 |
| Vitamin B12 | 68-19-9 | 0.005 |
| p-Amino benzoic acid (PABA) | 150-13-0 | 1.000 |
| OTHERS | ||
| D-Glucose | 50-99-7 | 4500.000 |
| Glutathione reduced | 70-18-8 | 1.000 |
| Phenol red sodium salt | 34487-61-1 | 5.300 |
| i-Inositol | 87-89-8 | 35.000 |
ISO 13485:2016 manufacturing & compliance
Manufactured under ISO 13485:2016 QMS, with final packaging, testing, and customization at Diagnocine Precision in Totowa, New Jersey, USA.
ISO 13485:2016 QMS
Full quality management system certification covering manufacturing, testing, and release for every production lot.
Ultrapure Type 1 Water
All media prepared with 18.2 MΩ·cm resistivity water meeting ASTM D1193 Type I / ISO 3696 purity standards.
ISO Class 5 Fill & Finish
Aseptic filling in validated ISO Class 5 laminar-flow workstations; 21 CFR Part 820 (QMSR) aligned.
Micro-Batch Precision
Small-batch manufacturing ensures lot-to-lot nutrient consistency for reproducible perfusion studies.
Endotoxin — USP <85> BET
LAL assay per batch. Release specification: < 0.05 EU/mL (assay sensitivity 0.005 EU/mL).
Particulate — USP <788> Method 1
Light obscuration particle count confirms ≥10 µm and ≥25 µm compliance on every batch.
Osmolality — USP <785>
Freezing-point osmometry per USP <785>. Result: See CoA.
Documentation — CoA & Full Lot Records
Certificate of Analysis with full QC panel, raw material traceability, and release signatures for every batch.
- Endotoxin — LAL assay, USP <85> Bacterial Endotoxins Test; assay sensitivity 0.005 EU/mL; release specification < 0.05 EU/mL
- pH, osmolality, conductivity, appearance and clarity
- Sterility
How DCP-RPMIG-QPB1X (FluxMPS™) compares
Side-by-side comparison against conventional 0.22 µm-filtered alternatives of the same base formulation.
| Parameter | DCP-RPMIG-QPB1X (FluxMPS™) | Conventional RPMI 1640 (0.22 µm) | Standard RPMI 1640 alternative |
|---|---|---|---|
| Grade | Microfluidics Suitable | Conventional grade | Conventional grade |
| Base Formulation | RPMI 1640, High Glucose w/o L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate | RPMI 1640 Standard | RPMI 1640 Equivalent |
| Final filtration pore size | 0.04 µm | 0.22 µm | 0.22 µm |
| Number of filtration stages | 4 stages | 1 stage | 1–2 stages |
| Mycoplasma barrier filtration | check_circle | cancel | cancel |
| Endotoxin (release specification) | FluxMPS™ — < 0.05 EU/mL | Corning classical liquid media — < 0.25 EU/mL Sigma-Aldrich DMEM complete medium — ≤ 2 EU/mL Gibco classical DMEM — Not specified (recorded per lot) |
|
| USP particulate compliance | check_circle USP <788> Method 1 | cancel | cancel |
| Water quality | Ultrapure Type 1 (18.2 MΩ·cm) | Purified water | Purified water |
| Manufacturing QMS | ISO 13485:2016 | Variable | Variable |
| Microfluidic channel compatibility | check_circle Validated | cancel Risk of clogging | cancel Risk of clogging |
| Custom formulation | check_circle On request | cancel | Limited |
Comparison figures from published supplier specifications, accessed 2026-09-02. Suppliers that publish no numeric endotoxin specification are shown as "Not specified".
Frequently asked questions
Common questions about FluxMPS™ RPMI 1640 Medium, High Glucose w/o L-Glutamine, Sodium Pyruvate, Sodium Bicarbonate: 1X Liquid and Microfluidics Suitable cell culture media.
Supporting literature
Peer-reviewed publications supporting the scientific rationale for Microfluidics Suitable ultra-filtered media and microfluidic cell culture applications.
- Huh D et al. (2010). Reconstituting organ-level lung functions on a chip. Science, 328(5986), 1662–1668. doi:10.1126/science.1188302
- Bhatia SN & Ingber DE (2014). Microfluidic organs-on-chips. Nature Biotechnology, 32(8), 760–772. doi:10.1038/nbt.2989
- Bhattacharya S et al. (2018). Challenges in maintaining cell viability during microfluidic experiments. Electrophoresis, 39(7), 997–1006. doi:10.1002/elps.201700375
- Warburg O (1956). On the origin of cancer cells. Science, 123(3191), 309–314. doi:10.1126/science.123.3191.309
- Kim S et al. (2012). Gut-on-a-chip microdevice replicates key functional features of the human intestine. Lab on a Chip, 12(12), 2165–2174. doi:10.1039/c2lc40074j
- Zhang YS et al. (2017). Multisensor-integrated organs-on-chips platform for automated in situ monitoring. PNAS, 114(12), E2293–E2302. doi:10.1073/pnas.1612906114
- Vernetti L et al. (2017). Functional coupling of human microphysiology systems. Scientific Reports, 7, 42296. doi:10.1038/srep42296
- Schuster B et al. (2020). Automated microfluidic platform for dynamic and combinatorial drug screening of tumor organoids. Nature Communications, 11, 5271. doi:10.1038/s41467-020-19058-4
- Zheng F et al. (2021). Organ-on-a-chip systems: microengineering to biomimic living systems. Small, 17(7), 2004175. doi:10.1002/smll.202004175
- Esch EW et al. (2015). Organs-on-chips at the frontiers of drug discovery. Nature Reviews Drug Discovery, 14(4), 248–260. doi:10.1038/nrd4539
